Technique parameter

 Frequency response: 38Hz-17.5KHz

 Component: 15"+72mm horn

 Sentivity(1W/1m): 99dB±3dB

 Max SPL(1M): 122dB cont, 125dB peak

 Nominal lmpedance: 8ohms

 RMS: 400W

 Peak: 800W

 Dispersion: 100H° X 70°V

 Shipping: 520mm 560mm 750mm

 NW/GW(KG): 23.5.5KG/25KG

技术参数

 频响:38Hz-17.5KHz

 单元:15"+72mm horn

 灵敏度: 99dB±3dB

 最大声压级:122dB cont, 125dB peak

 阻抗:8ohms

 连续功率:400W

 峰值功率:800W

 辐射角:100H° X 70°V

 尺寸: 520mm 560mm 750mm

 重量: 23.5.5KG/25KG
